In recent years, with the development of urban public transport, efforts have been made to create a model city of traffic civilization. As a city image publicity, bus shelters play a very important role and responsibility. At the same time, it also provides a convenient, fast, and comfortable waiting environment for citizens to travel. There are much professional common sense and design elements in the production process of the bus shelter, which also left a sense of mystery for many customers. The manufacturer of the bus shelter will introduce the process flow and key points in the production process of the bus shelter!

First of all, the customized manufacturer of the bus shelter needs to determine the customer's requirements, so that the design department can design the bus shelter according to the customer's ideas and the actual situation. After the design of renderings and floor plans is completed, we need to communicate with customers to determine, and then submit them to the engineers and technicians in charge of production in the workshop for production and processing.

1、 Determine the basic dimensions of the shelter:

1. Shelter size: customizable;

2. Shelter color: customizable;

3. Wind resistance: Grade 12; Seismic grade: 8;

2、 Make lightbox layout:

1. The outer frame is sprayed with the imported metal fluorocarbon paint of the national standard cold plate, with the built-in integrated on-board EPDM sealing rubber strip, combined with the layout of the water guide system, which is waterproof and dustproof, and has a corrosion protection life of more than 10 years;

2. The inner frame is sprayed with the imported metal fluorocarbon paint of the national standard cold plate, which is completely processed according to the national standard process flow. Install the surrounding water seal, lining plate, heat dissipation equipment, leakage maintenance, and other electrical appliances;

3.6mm automobile level float toughened glass window, screen printed protective edge, anti-aging period of more than 20 years;

4. The light source of the box is an LED side light source, with overvoltage, overcurrent, and reverse connection , functions;

5. Built-in anti-theft lock, easy to open;

6. National standard cold plate, fully CNC shearing and bending, CNC slotting of bending line, to prevent bending fillet. The door frame adopts dead-edge technology, and the window function is almost plain, beautiful, and elegant;

3、 Column production:

The inner core of the column is made of high-strength cold galvanized steel, sprayed with imported metal fluorocarbon paint, and processed according to the national standard process flow. The connection between the buried flange and the grounding cage is made of high-strength 45 # steel, with a planned wind resistance of 12 and a seismic resistance of 8; The column is wrapped with a galvanized sheet, fully CNC bending forming, and the bending part is grooved to prevent bending; The CNC bending machine has a unique winding compensation function to ensure the straightness of crimping.

4、 LED display screen of bus stop:

The integrated equipment bracket is equipped with an outdoor high-definition bright LED display module;

5、 Waterproof ceiling production:

1. Upper ceiling: National standard cold plate imported plastic powder antirust treatment, imported metal fluorocarbon paint spraying;

2. Lower ceiling: 4mm thick aluminum-plastic plate for outdoor use, 0.5mm thick aluminum layer, external arrangement of the ceiling: high-strength galvanized square tube, sprayed with imported metal fluorocarbon paint.

6、 Determine the construction of embedded parts according to the actual situation. The engineer debugs the power supply rolling system. After the commissioning is qualified, it can be placed and shipped, and then the components can be assembled. A new bus shelter was built in this way.

The process flow and key points of the production and production of the bus stop are welcome to consult if there is any demand for project procurement.
